KAYO MOTO AUSTRALIA S200 BUGGY
)
)
)
)
)
)
| Engine | |
|---|---|
| Engine Type: | Single cylinder, 4-stroke, oil cooling, Vertical engine |
| Displacement (ml): | 196.2mL |
| Rated Power (kw/rpm): | 10/7000 |
| Gear Shift: | CVT, R-N-F |
| Starting: | Electric |
| Transmission: | CVT |
| Ignition: | CDI |
| Battery: | 12V14AH |
| Performance | |
| Acceleration(s): | < 20 |
| Max Speed (km/h): | > 50kph* (Depends on road condition and rider’s weight) |
| Side-slip Distance: | + 5m/km |
| Max Climbing Performance: | > 25° |
| Lateral Roll Tilt Angle: | > 25° |
| Steering Angle: | < 45° |
| Brake Power (n): | Front:> 460 – Rear:> 500 |
| Chassis | |
| Front Shock(mm): | L=420 |
| Rear Shock(mm): | L=480 |
| Rear: | 150 |
| Front & Rear Brake: | Disc |
| Suspension Travel(mm): | Front : 130 – Rear:150 |
| Rear Swingarm: | Double A arm |
| Front Rim: | 10*5.5AT-4/110 Black |
| Rear Rim: | 10*8.0AT-4/110 Black |
| Framework: | Professional design and processed by KAYO |
| Steering Wheel: | Rubber Coated Steering Wheel Dia 350 mm |
| Dimensions and Capacities | |
| LxWxH (mm): | 2517 x 1487 x 1446 |
| Package (mm): | 2700 x 1440 x 850 |
| Wheelbase (mm): | 1900 |
| Dry weight (kg): | 320 |
| Seat Height (mm): | 410 |
| Min Ground Clearance (mm): | 230 |
| Fuel Capacity (L): | 15 |
| Tires: | Front Tire :AT22*7.0-10 – Rear Tire : AT22*10-10 |
